If you take a closer look at ÄNGSJÖN, you’ll soon discover the small details that make a difference to both form and function. Designer Sarah Fager demonstrates how the integrated handle on the cabinets and drawers contributes to the calm feel. “The handle extends across the entire drawer front and cabinet door, making it easy to grip. On the drawer, it’s also facing downwards to not collect dust and dirt.” Sarah has also designed BACKSJÖN wash-basin with clean lines. It goes perfectly together with ÄNGSJÖN. “It’s made of crushed marble, which can be made slightly thinner and neater than porcelain without losing strength. In addition to achieving a light feel, we managed to reduce the weight of the wash-basin compared to previous models.“
BROGRUND
Wash-basin mixer tap, chrome-plated
- Brand NameIKEA
- Type of tapWash-basin mixer tap
- Max. flow rate at 3 bar5.7 l/min
- Annual energy consumption343 kWh/p.a.
- Recommended working pressure1 - 5 bar (0.1 - 0.5 MPa) (14.5 - 72.5 psi)
- Min. working pressure0.5 bar (0,05MPa) (7.25 psi)
- Max. static pressure10 bar (1,0MPa) (145.0 psi)
- Max. countertop thickness50 mm (2")
- Mounting hole measurement34-37 mm (1 3/8-1 7/16")
- Connection hoses length475 mm (18 3/4")
- Hose connection sizeG 3/8" (R10)
- Recommended cold water temperature10-15˚C (50-59˚F)
- Recommended hot water temperature60-65°C (140-150°F)
- Max. hot water temperature80˚C (176˚F)
- Strainer includedNo
- Third party certified according to local standards byACS, ETA-Danmark, BELGAQUA, KIWA, PZH, SINTEF
