Product details
Cabinet code SE B1D3I
MAXIMERA drawer is a smooth-running, full-extension drawer with built-in dampers so that it closes slowly, softly, and quietly.
The door damper prevents your cabinet door from slamming by catching the moving door so that it closes slowly, gently and silently.
The door can be mounted to open to the left or right.
Snap-on hinges can be mounted onto the door without screws, and you can easily remove the door for cleaning.
Sturdy frame construction, ¾" thick.
25-year Limited Warranty. Read about the terms in the Limited Warranty brochure.
Different wall materials require different types of fasteners. Use fasteners suitable for the walls in your home.
The hinge is adjustable in height, depth and width.
Requires a knob or a handle
To be completed with SEKTION suspension rail for mounting the cabinet to the wall.
Suspension rail sold separately.
To be completed with legs and plinth, sold separately.
- Door frame:
- Fiberboard, Plastic foil, Plastic edging
- Door filling:
- Fiberboard, Plastic foil
- Frame:
- Particleboard, Melamine foil, Plastic edging
- Back:
- Fiberboard, Acrylic paint
- Front rail:
- Steel, Galvanized
- Drawer/ Drawer back/ Drawer rail:
- Steel, Epoxy/polyester powder coating
- Runners:
- Galvanized steel
- Drawer bottom:
- Particleboard, Melamine foil, Melamine foil
- Fiberboard, Acrylic paint
Wipe clean with a damp cloth. Use only water or a non-abrasive detergent.
Wipe dry with a clean cloth.
Measurements
- Width: 53.3 cm (21 ")
- System, depth: 61 cm (24 ")
- Depth: 62.8 cm (24 3/4 ")
- Frame, height: 76.2 cm (30 ")
This product comes as 9 packages.
DoorArticle Number705.167.31- Width: 54 cm (21 ¼ ")
- Height: 2 cm (¾ ")
- Length: 83 cm (32 ½ ")
- Weight: 3.78 kg (8 lb 5 oz)
- Package(s): 1
Base cabinet frameArticle Number302.654.14- Width: 61 cm (24 ")
- Height: 7 cm (2 ¾ ")
- Length: 85 cm (33 ½ ")
- Weight: 17.65 kg (38 lb 15 oz)
- Package(s): 1
Hinge w b-in damper for kitchenArticle Number104.272.62- Width: 22 cm (8 ¾ ")
- Height: 6 cm (2 ¼ ")
- Length: 26 cm (10 ¼ ")
- Weight: 0.43 kg (15 oz)
- Package(s): 1
Drawer, mediumArticle Number602.656.72- Width: 45 cm (17 ½ ")
- Height: 7 cm (2 ½ ")
- Length: 56 cm (21 ¾ ")
- Weight: 6.38 kg (14 lb 1 oz)
- Package(s): 3
Drawer front, mediumArticle Number302.656.35- Width: 17 cm (6 ½ ")
- Height: 2 cm (¾ ")
- Length: 51 cm (20 ")
- Weight: 0.88 kg (1 lb 15 oz)
- Package(s): 3
Ratings and reviews
Bottom hinge leads to a lot of wasted space at bottomKarynI didn't realize this when designing the kitchen as it doesn't show it this way in the kitchen planner, but when actually building the cabinet it turns out because of the door hinges you have to move the bottom drawer up several inches, leading to a lot of wasted space at the bottom. Very disappointed in that.1
Hoping for a pull-out door (not hinged)RoyNice cabinet with recessed drawers. However, I modified mine to have the door open as a pull-out rather than hinged. I connected the lower drawer slides (with the drawer) directly to the door, and added a second set of drawer slides (only) about half way up. Wish IKEA offered this option.4
Make a 21 drawer front!Anonymous reviewerWe have two of the cupboards in our kitchen. My wife wanted lots of drawers and with the dimensions of our kitchen, we had to get these cabinets. While we like the drawers, there is so much wasted space in this cabinet because of the door hinges. Why not just make a 21 drawer front? Then we would also be able to put in the secret drawer at the top and make this cabinet MUCH more useful.2
