HAVBÄCK / ORRSJÖN Sink cab w drawers/sink/taps, dark gray, 124.6x55.3x70.3 cm (49x21 3/4x27 5/8 ")
How to get it
10 year limited warranty
What do you get when you combine 2 of everything? Generous storage space and double the washing space! A brilliant solution with plenty of space for 2 or more to get ready in the morning.
Product details
Uncomplicated design matched with a matt dark gray finish gives your bathroom a confident expression and a warm sense of calm that is easy to personalize with your choice of knobs or handles.
Depending on your space and needs, complete this solution with your choice of a mirror or mirror cabinet from our range, sold separately.
This combo with 2 sink cabinets, each with 2 drawers, allows you to divide the storage space between members of the household. The double sink is perfect when everyone is on the same clock.
Set your style with your choice of knobs and/or handles from our range, sold separately.
The ceramic double-bowl sink with its soft shapes and durable surface is made with the best materials and will outlast many years of wear and tear.
This combination is to be wall-mounted. This creates a spacious feel but also makes it easier to clean floors underneath. It is also possible to add legs depending on the look you prefer.
Combine with other cabinets in the HAVBÄCK series to create a coordinated bathroom solution that fits your space and needs.
10-year Limited Warranty. Read about the terms in the Limited Warranty brochure.
Good to know
If you are uncertain about the installation, contact a professional. The installation shall be made in accordance with valid local building and plumbing regulations.
Silicone is needed for installation, not included.
Knobs and handles are sold separately.
Materials and care
Material
- Frame/ Middle rail/ Drawer front/ Drawer sides/ Drawer divider:
- Particleboard, Plastic foil, Plastic edging, Plastic edging (min. 50% recycled)
- Top rail:
- Fiberboard, Plastic foil, Plastic edging, Plastic edging (min. 50% recycled)
- Drawer back:
- Particleboard, Plastic foil
- Drawer bottom:
- Fiberboard, Plastic foil
- Cover/ Spring:
- Stainless steel
- Cover cap/ Mechanism:
- Acetal plastic
- Sealing ring:
- Synthetic rubber
- Cover cap:
- Polycarbonate/ABS plastic
- Main parts:
- Ceramic, Colored glaze
- Spout:
- Stainless steel, Metallized
- Handle:
- Zinc, Metallized
- Water trap frame/ Nut/ Outlet pipe:
- Polypropylene
- Washer/ Seals:
- Synthetic rubber
- Waste pipe:
- Synthetic rubber, Polypropylene
- Strainer:
- Stainless steel
- Assembly tool:
- ABS plastic
Care
Wipe clean with a mild soapy solution.
Wet marks should always be dried off as soon as possible to stop moisture penetration.
Wipe dry with a clean cloth.
Do not use scouring powder, steel wool, hard or sharp tools which can scratch the surface of the sink.
Safety and compliance
Assembly and documents
Assembly instructions
HAVBÄCK Sink cabinet with drawers605.352.02ORRSJÖN Double sink506.054.41ORRSJÖN Double sink506.054.41MACKSJÖN Center set sink faucet606.044.22RÄNNILEN Water trap, 2 bowls205.624.38Advice and care instructions
HAVBÄCK Sink cabinet with drawers605.352.02MACKSJÖN Center set sink faucet606.044.22TECHNICAL INFORMATION
MACKSJÖN
Center set sink faucet, brushed nickel, 10 cm (4 ")
Article Number606.044.22| Type of faucet | Sink faucet, |
| Max. flow rate at 3 bar | 4.5 l/min (1.2 gpm) |
| Recommended working pressure | 1 - 5 bar (0.1 - 0.5 MPa) (14.5 - 72.5 psi) |
| Min. working pressure | 0.5 bar (0,05MPa) (7.25 psi) |
| Max. static pressure | 10 bar (1,0MPa) (145.0 psi) |
| Max. countertop thickness | 50 mm (2") |
| Hose connection size | 9/16" x 24UNEF |
| Recommended cold water temperature | 10-15˚C (50-59˚F) |
| Recommended hot water temperature | 60-65°C (140-150°F) |
| Max. hot water temperature | 80˚C (176˚F) |
| Third party certified according to local standards by |
Measurements
- Width: 124.6 cm (49 ")
- Depth: 55.3 cm (21 3/4 ")
- Height: 70.3 cm (27 5/8 ")
Packaging
HAVBÄCK
Article Number605.352.02- Width: 63 cm (24 ¾ ")
- Height: 6 cm (2 ½ ")
- Length: 82 cm (32 ¼ ")
- Weight: 17.36 kg (38 lb 4 oz)
- Package(s): 2
- Width: 35 cm (13 ¾ ")
- Height: 10 cm (3 ¾ ")
- Length: 61 cm (23 ¾ ")
- Weight: 10.82 kg (23 lb 13 oz)
- Package(s): 2
ORRSJÖN
Article Number506.054.41- Width: 60 cm (23 ½ ")
- Height: 19 cm (7 ¼ ")
- Length: 128 cm (50 ½ ")
- Weight: 37.00 kg (81 lb 9 oz)
- Package(s): 1
MACKSJÖN
Article Number606.044.22- Width: 22 cm (8 ½ ")
- Height: 16 cm (6 ¼ ")
- Length: 34 cm (13 ¼ ")
- Weight: 1.59 kg (3 lb 8 oz)
- Package(s): 2
RÄNNILEN
Article Number205.624.38- Width: 35 cm (13 ¾ ")
- Height: 10 cm (4 ")
- Length: 60 cm (23 ½ ")
- Weight: 0.96 kg (2 lb 2 oz)
- Package(s): 1
