- Brand NameIKEA
- Model IdentifierUNDERVERK 10393974
- Annual energy consumption39 kWh/annum
- Energy efficiency classA+
- Fluid Dynamic Efficiency34.8 %
- Fluid Dynamic Efficiency classA
- Lighting Efficiency37.0 Lux/watt
- Lighting Efficiency classA
- Grease Filtering Efficiency95.1 %
- Grease Filtering Efficiency classA
- Air flow at minimum speed in normal use240 m³/h
- Air flow at maximum speed in normal use630 m³/h
- Air flow at maximum speed in normal use, recirculation365 m³/h
- Air flow at intensive or boost settingn/a m³/h
- Airborne acoustical A-weighted sound power emissions at minimum speed available in normal use45 dB
- Airborne acoustical A-weighted sound power emissions at maximum speed available in normal use64 dB
- Airborne acoustical A-weighted sound power emissions art maximum speed available in normal use, recirculation79 dB
- Airborne acoustical A-weighted sound power emissions at intensive or boost settingn/a dB
- Power consumption in Off mode0 Watt
- Power consumption in standby mode0 Watt
Flexible pipe for fan and charcoal filter sold separately.
How to get it
Collect 75 points with
UNDERVERK
103.939.74Hidden inside your 80 cm cabinet, this powerful hood works in secret – just choose the doors you like to get a uniform look in the kitchen. The LED light source provides even lighting over the hob.
Product features
5 year guarantee
More information
5 year guarantee. Read about the terms in the guarantee brochure.
Can be installed in two ways, either ducted to the outside or in recirculation mode fitted with charcoal filter.
Fully integrated; hidden behind your kitchen cabinet door, creating a uniform expression.
LED light source included; effectively illuminates the cooking surface and provide energy saving.
Customer reviews
3Average rating
104Reviews
3Average rating
104Reviews
Related products
Explore more options
Recommended for you
Quality
Sensitive to noise or have an open-plan home?
For extractor hoods, a noise level below 60 dB is considered low – roughly equivalent to a normal conversation between two people. We measure the noise level of our hoods at max speed, making it easier to compare different models. Note that sound levels decrease at lower speeds, and recirculating hoods are typically louder than those vented outdoors. Noise may also increase if the ducting is long or has several bends, as the air has to work harder to pass through the system.
Function solution
Sound levels
Sound levels for appliances are measured in decibels (dBs). Our extractor hoods have been tested in speed 3 to determine the dB level. The sound level of your extractor hood is affected by: • Type of installation. Exhaust-mode or recirculation-mode. • Length and diameter of the exhaust pipe between extractor and exhaust vent. The longer it is and the smaller the diameter, the louder it gets. • 90° bends. The more bends you have in the exhaust pipe, the greater the sound.
