- Type of tapWash basin mixer tap, tall
- Max. flow rate at 3 bar4.5 l/min (1.2 gpm)
- Recommended working pressure1 - 5 bar (0.1 - 0.5 MPa) (14.5 - 72.5 psi)
- Min. working pressure1 bar (0,1MPa) (14.5 psi)
- Max. static pressure10 bar (1,0MPa) (145.0 psi)
- Max. countertop thickness50 mm (2")
- Mounting hole measurement34-37 mm (1 3/8-1 7/16")
- Connection hoses length500 mm (19 3/4")
- Hose connection sizeG 1/2" (R15) "
- Recommended cold water temperature10-15˚C (50-59˚F)
- Recommended hot water temperature60-65°C (140-150°F)
- Max. hot water temperature80˚C (176˚F)
Related products
VOXNAN
105.331.68You save hot water and energy every time you lift the lever. The cold start function avoids the unnecessary use of hot water for daily rituals like washing your hands or brushing your teeth.
Product features
10 year guarantee
- Suitable for business
More information
10 year guarantee. Read about the terms in the guarantee brochure.
Hot water is released by turning the lever to the left. It is only then that hot water is consumed.
This is a durable mixer tap that you can use for many years, since the hard, ceramic discs withstand the friction that always occurs when you change the temperature of the water.
Chrome-plated brass is a hard and durable surface that is easy to clean.
Designer
H Preutz/N Karlsson
