- Type of tapKitchen mixer tap
- WELS ratingB
- Recommended working pressure1 - 5 bar (0.1 - 0.5 MPa) (14.5 - 72.5 psi)
- Min. working pressure0.5 bar (0,05MPa) (7.25 psi)
- Max. static pressure10 bar (1,0MPa) (145.0 psi)
- Max. worktop thickness50 mm (2")
- Mounting hole measurement34-37 mm (1 3/8-1 7/16")
- Connection hoses length450 mm (17 3/4")
- Hose connection sizeG 3/8" (R10)
- Swivel spoutSwivel spout is preset to 360° but can be changed to 120°.
- Recommended cold water temperature10-15˚C (50-59˚F)
- Recommended hot water temperature60-65°C (140-150°F)
- Max. hot water temperature80˚C (176˚F)
- Strainer includedNo
- Third party certified according to local standards bySASO
How to get it
Checking availability...INSJÖN
604.939.8510 year guarantee. Read about the terms in the guarantee brochure.
Product features
10 year guarantee
- Swivel spout 120°
- Aerator
More information
Material
- Body:
- Brass, Chrome-plated
- Spout:
- Brass, Brass, Chrome-plated
- Handle:
- Zinc, Chrome-plated
Care
Do not use scouring-powder, steel wool, hard or sharp tools which can scratch the surface.
Wipe dry with a clean cloth.
To remove larger limescale deposits – use diluted, ordinary white vinegar and rinse with water.
Clean with a soft damp cloth only using water and a mild washing-up detergent or soap. Never use scouring powder, steel wool, a descaling agent or a detergent that is acidic or contains alcohol or an abrasive.
Assembly instructions
INSJÖN Kitchen mixer tap604.939.85Advice and care instructions
INSJÖN Kitchen mixer tap604.939.85
The mixer tap insert has hard, durable ceramic discs that can handle the high friction that occurs when you change the temperature of the water.
The high spout makes it easier to wash dishes, including large pots.
Chrome-plated brass is a hard and durable surface that is easy to clean.
Designer
Brickstad/Palleschitz/Petersén
If you are uncertain about the installation, contact a professional. The installation shall be made in accordance with valid local building and plumbing regulations.
To be mounted in a 35 mm hole in a max. 70 mm thick sink/worktop.
A tool is included that makes it easy to install the mixer tap in place.
Connection hoses with 3/8" connection included. Length: 45 cm.
Max. temperature hot water system 80°C/176°F.
Swivel spout is preset to 360° but can be changed to 120°.
Material
- Body:
- Brass, Chrome-plated
- Spout:
- Brass, Brass, Chrome-plated
- Handle:
- Zinc, Chrome-plated
Care
Do not use scouring-powder, steel wool, hard or sharp tools which can scratch the surface.
Wipe dry with a clean cloth.
To remove larger limescale deposits – use diluted, ordinary white vinegar and rinse with water.
Clean with a soft damp cloth only using water and a mild washing-up detergent or soap. Never use scouring powder, steel wool, a descaling agent or a detergent that is acidic or contains alcohol or an abrasive.
- Tested and certified to relevant national and international mechanical, quality, safety and hygienic standards.This tap is for use on high pressure water systems. Tested to work with a max. pressure of 10 bar (1000 kPa). Recommended working pressure range is 1.0 – 5.0 bar (100 kPa – 500 kPa).
Assembly instructions
INSJÖN Kitchen mixer tap604.939.85Advice and care instructions
INSJÖN Kitchen mixer tap604.939.85
- 604.939.85
1 × INSJÖN
Kitchen mixer tap- Width: 35 cm
- Height: 8 cm
- Length: 53 cm
- Weight: 2.66 kg
