- Type of tapWash-basin mixer tap
- Max. flow rate at 3 bar4.5 l/min (1.2 gpm)
- Recommended working pressure1 - 5 bar (0.1 - 0.5 MPa) (14.5 - 72.5 psi)
- Min. working pressure0.5 bar (0,05MPa) (7.25 psi)
- Max. static pressure10 bar (1,0MPa) (145.0 psi)
- Max. countertop thickness50 mm (2")
- Mounting hole measurement34-37 mm (1 3/8-1 7/16")
- Connection hoses length350 mm (13 3/4")
- Hose connection sizeG 1/2" (R15) "
- Recommended cold water temperature10-15˚C (50-59˚F)
- Recommended hot water temperature60-65°C (140-150°F)
- Max. hot water temperature80˚C (176˚F)
BROGRUND
805.321.1310 year guarantee. Read about the terms in the guarantee brochure.
Product features
10 year guarantee
- Suitable for business
More information
Material
Brass, Chrome-plated
Care
Wipe clean with a soft cloth dampened in water and a mild non-abrasive washing-up detergent or soap, if necessary.
Never use scouring powder, steel wool or a detergent that is calcium-dissolving, sour or contains alcohol or an abrasive.
Assembly instructions
BROGRUND Wash-basin mixer tap805.321.13Advice and care instructions
BROGRUND Wash-basin mixer tap805.321.13BROGRUND Wash-basin mixer tap805.321.13
Hot water is released by turning the lever to the left. It is only then that hot water is consumed.
This is a durable mixer tap that you can use for many years, since the hard, ceramic discs withstand the friction that always occurs when you change the temperature of the water.
Chrome-plated brass is a hard and durable surface that is easy to clean.
Designer
H Preutz/N Karlsson
Connection hoses with 1/2" connection included. Connection length: 50 cm.
A tool is included that makes it easy to install the mixer tap in place.
Max. temperature hot water system 80°C/176°F.
If you are uncertain about the installation, contact a professional. The installation shall be made in accordance with valid local building and plumbing regulations.
Fits IKEA wash-basins and standard wash-basins from other manufacturers.
Material
Brass, Chrome-plated
Care
Wipe clean with a soft cloth dampened in water and a mild non-abrasive washing-up detergent or soap, if necessary.
Never use scouring powder, steel wool or a detergent that is calcium-dissolving, sour or contains alcohol or an abrasive.
- Tested and certified to relevant national and international mechanical, quality, safety and hygienic standards.
Assembly instructions
BROGRUND Wash-basin mixer tap805.321.13Advice and care instructions
BROGRUND Wash-basin mixer tap805.321.13BROGRUND Wash-basin mixer tap805.321.13
- 805.321.13
1 × BROGRUND
Wash-basin mixer tap- Width: 18 cm
- Height: 6 cm
- Length: 35 cm
- Weight: 1.50 kg
