ROGESTAD
705.595.135 year guarantee. Read about the terms in the guarantee brochure.
Care
Do not use scouring-powder, steel wool, hard or sharp tools which can scratch the surface.
After cleaning, be sure to wipe dry with a soft cloth.
Remove stains and food residue after each use using a cloth damped with warm water and a mild detergent.
Assembly instructions
ROGESTAD Induction hob705.595.13
Induction hobs are extremely energy efficient, fast and precise as induction technology transfers energy directly into magnetic cookware.
Gives you the flexibility to use larger and different pots for special recipes or occasions as the bridge function allows you to connect 2 cooking zones into 1 large one when needed.
When the hob is on, the cooking zone activates automatically when you place the pot on it. All you need to do is choose the power level.
Each zone has an auto cooking function. By pressing on the symbol, the zone heats to a melting setting with just the right temperature for melting things like chocolate or butter.
Hob with induction cooking zones:
Right front: 16 cm – 1400W, booster 2100W.
Left front: 21x19 cm – 2100W, booster 3000W.
Left rear: 21x19cm – 2100W, booster 3000W.
Right rear: 20 cm - 2300W, booster 3000W.
Voltage: 220-240V.
Connection rating: 7400W.
Current: 2x16A or 1x32A.
Number of zones: 4.
Pause.
Child lock.
Timer.
Booster (4 zones).
Bridge function.
Touch and slide.
Cord/cable not included. Wired-in installation. Installation must be made by a qualified electrician or specialist.
When installing your hob in a base cabinet with drawers, complete with NYTTIG hob separator for drawer. The protective barrier prevents reaching the hob from below and getting burned.
Cooking zones are grouped (left or right) and connected to phases, each with a maximum power supply. When using more than one zone connected to the same phase, the hob divides the power between them.
The power setting of the last selected cooking zone is prioritised. Power to the previously activated cooking zone is reduced to match the maximum supply.
You will find complete information about the installation and use of this product under the tab Assembly instructions & documents.
Induction hobs requires cookware with magnetic base.
The hob may produce low humming, whistling or ticking sounds. These sounds are caused by the induction technology and they are completely normal.
IKEA of Sweden AB SE-343 81 Älmhult, IKEA.com
Care
Do not use scouring-powder, steel wool, hard or sharp tools which can scratch the surface.
After cleaning, be sure to wipe dry with a soft cloth.
Remove stains and food residue after each use using a cloth damped with warm water and a mild detergent.
- This product bears the CE mark.This product bears the UK CA mark.This product bears the Serbian mark of conformity.
Assembly instructions
ROGESTAD Induction hob705.595.13
- 705.595.13
1 × ROGESTAD
Induction hob- Width: 63 cm
- Height: 15 cm
- Length: 87 cm
- Weight: 13.40 kg
